ACS724KMATR-30AU-T - Allegro MicroSystems
ACS724 Series 5.5 V 30 A 80 kHz SMT Hall Effect Current Sensor - SOIC-16
Technical Details
| Accuracy | 0.7% |
| Ambient Temperature Range High | 125°C |
| Body Material | Plastic |
| China RoHS | Compliant |
| Height | 2.34mm |
| Height - Seated (Max) | 2.65mm |
| Introduction Date | 2016-03-18 |
| Length | 10.21mm |
| Lifecycle Status | Production |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 16 |
| Operating Supply Current | 10mA |
| Operating Supply Voltage | 5V |
| Output Configuration | Analog |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sensing Method | Hall Effect |
| Temperature Grade | Automotive |
| Terminal Pitch | 1.27mm |
| Width | 7.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
