| Body Material | Stainless Steel |
| Body Plating | Passivated |
| Case/Package | SMA |
| Connector Type | SMA, Socket |
| Contact Gender | Female |
| Contact Material | Copper |
| Contact Plating | Gold |
| Dielectric Material | PTFE |
| Fastening Type | Threaded |
| Frequency | 12.4GHz |
| Gender | Female |
| Impedance | 50Ω |
| Insertion Loss (dB) | 0.11dB |
| Insulation Resistance | 5GΩ |
| Lead Free | Lead Free |
| Length | 38.1mm |
| Lifecycle Status | Production |
| Max Frequency | 12.4GHz |
| Max Operating Temperature | 165°C |
| Min Operating Temperature | -65°C |
| Mount | Bulkhead, Front Side Nut, Panel |
| Number of Pins | 1 |
| Number of Ports | 1 |
| Orientation | Straight |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Shell Material | Stainless Steel |
| Termination | Solder |
| Voltage Rating | 500V |
