| Case/Package | TSSOP |
| Current - Output 1 | 1.5A |
| Current - Output 2 | 1A |
| Efficiency | 95% |
| Height | 1.2mm |
| Lead Free | Lead Free |
| Length | 6.6mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Duty Cycle | 100% |
| Max Input Voltage | 5.5V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 85°C |
| Max Output Current | 1.4A |
| Max Output Voltage | 5V |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 2.25V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 800mV |
| Min Supply Voltage | 2.25V |
| Number of Channels | 1 |
| Number of Outputs | 2 |
| Number of Pins | 20 |
| Output Configuration | Positive |
| Output Current | 1.5A |
| Output Type | Adjustable |
| Output Voltage | 5V |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|8542390000|85 |
| Switching Frequency | 4MHz |
| Synchronous Rectifier | Yes |
| Topology | Buck |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 5V |
| Width | 4.3mm |
