| Contact Current Rating | 400mA |
| Contact Material | Gold, Silver |
| Contact Resistance | 50mΩ |
| Country of Origin | UK |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 500kcycles |
| Height | 43.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.33 |
| Introduction Date | 2008-09-12 |
| Lead Length | 500mm |
| Length | 32mm |
| Lifecycle Status | Production |
| Max Current Rating | 100mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 50V |
| Min Operating Temperature | -40°C |
| Ratings | IP67 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | IP67 |
| Termination | Plug |
| Throw Configuration | SPST |
