| Breakdown Voltage | 9.36V |
| Case/Package | SMA |
| China RoHS | Non-Compliant |
| Clamping Voltage | 13.6V |
| Composition | Zener |
| Country of Origin | Taiwan |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2010-02-23 |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 9.83V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 1W |
| Max Reverse Leakage Current | 100µA |
| Max Surge Current | 40A |
| Min Breakdown Voltage | 8.89V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 3.5V |
| Peak Pulse Current | 29.4A |
| Peak Pulse Power | 400W |
| Peak Reverse Current | 100µA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 8V |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|8541100080|85 |
| Termination | SMD/SMT |
| Test Current | 1mA |
