| Actuator Length | 7.747mm |
| Color | Yellow |
| Contact Current Rating | 400mA |
| Contact Plating | Gold, Silver |
| Contact Resistance | 50mΩ |
| Contact Voltage Rating (AC) | 32V |
| Electrical Life | 500kcycles |
| Height | 16.35mm |
| Insulation Resistance | 1GΩ |
| Length | 12.35mm |
| Lifecycle Status | Production |
| Max Current Rating | 200mA |
| Max Operating Temperature | 105°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -40°C |
| Number of Positions | 2 |
| Operating Force | 5N |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | EPOXY TERMINAL SEALED, IP67 |
| Throw Configuration | SPST |
