| Actuator Length |
800µm |
| Actuator Material |
PBT, Polybutylene |
| Contact Material |
Brass |
| Contact Plating |
Silver |
| Contact Resistance |
100mΩ |
| Country of Origin |
Mainland China |
| Current Rating |
50mA |
| Depth |
13.8mm |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Height |
3.5mm |
| Harmonized Tariff Schedule (HTS) Code |
8536.50.90.40 |
| Illumination Type |
Non-Illuminated |
| Insulation Resistance |
100GΩ |
| Introduction Date |
2009-04-08 |
| Lead Free |
Lead Free |
| Length |
12mm |
| Lifecycle Status |
Obsolete |
| Max Current Rating |
50mA |
| Max Operating Temperature |
60°C |
| Max Voltage Rating (DC) |
12V |
| Mechanical Life |
200kcycles |
| Min Operating Temperature |
-40°C |
| Mount |
PCB, Through Hole |
| Number of Poles |
1 |
| Number of Positions |
1 |
| Operating Force |
1.57N |
| Orientation |
Straight |
| Radiation Hardening |
No |
| REACH SVHC |
Yes |
| RoHS |
Compliant |
| Switch Function |
Off-Mom |
| Termination |
PC Pins |
| Throw Configuration |
SPST |
| Voltage Rating (DC) |
12V |
