| Accuracy | 1.5% |
| Case/Package | SOP |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fault Protection | Over Temperature, Reverse Current |
| Height | 1.5mm |
| Height - Seated (Max) | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Interface | On/Off |
| Introduction Date | 2009-11-13 |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Max Input Voltage | 6V |
| Max Operating Temperature | 85°C |
| Max Output Current | 2A |
| Max Supply Voltage | 5.5V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -35°C |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 5V |
| Output Configuration | High Side |
| Output Current | 2A |
| Output Type | Fixed |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 55µA |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Resistance | 170mΩ |
| RoHS | Compliant |
| Terminal Pitch | 1.27mm |
| Turn-Off Delay Time | 4µs |
| Turn-On Delay Time | 50µs |
| Weight | 850.995985mg |
| Width | 3.9mm |
