| China RoHS | Compliant |
| Dimming | PWM |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 1MHz |
| Height - Seated (Max) | 1.63mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2013-11-12 |
| Length | 4.9mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 60V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 6V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Characters | 2 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 24V |
| Output Current per Channel | 1A |
| Output Voltage | 60V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Automotive |
| Terminal Pitch | 1.27mm |
| Width | 3.9mm |
