| Breakdown Voltage |
27.65V |
| Clamping Voltage |
39.4V |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Harmonized Tariff Schedule (HTS) Code |
85411000 |
| Introduction Date |
2001-11-23 |
| Lifecycle Status |
Production |
| Manufacturer Lifecycle Status |
ACTIVE |
| Max Breakdown Voltage |
30.9V |
| Max Operating Temperature |
175°C |
| Max Power Dissipation |
8W |
| Min Breakdown Voltage |
24.4V |
| Min Operating Temperature |
-50°C |
| Mount |
Axial |
| Number of Elements |
1 |
| Number of Terminals |
2 |
| Peak Pulse Power |
5kW |
| Peak Reverse Current |
10µA |
| Polarity |
Bidirectional |
| REACH SVHC |
Unknown |
| Reverse Standoff Voltage |
22V |
| RoHS |
Compliant |
| Weight |
1.722g |
