| Breakdown Voltage | 49.3V |
| Clamping Voltage | 71.4V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 85411000 |
| Introduction Date | 2001-12-05 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 54.2V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 1W |
| Min Breakdown Voltage | 44.4V |
| Min Operating Temperature | -50°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Power | 400W |
| Peak Reverse Current | 5µA |
| Polarity | Unidirectional |
| REACH SVHC | Unknown |
| Reverse Standoff Voltage | 40V |
| RoHS | Compliant |
| Weight | 126mg |
