| Actuator Material |
Polyethylene |
| Body Material |
Thermoplastic |
| Contact Plating |
Gold |
| Contact Resistance |
20mΩ |
| Country of Origin |
Mainland China |
| Current Rating |
25mA |
| Depth |
8.13mm |
| Dielectric Material |
Polyethylene |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Electrical Life |
2kcycles |
| Height |
4.19mm |
| Housing Material |
Polyethylene |
| Harmonized Tariff Schedule (HTS) Code |
8536.50.90.65 |
| Insulation Resistance |
5GΩ |
| Introduction Date |
2007-04-30 |
| Length |
7.37mm |
| Lifecycle Status |
Production |
| Max Current Rating |
100mA |
| Max Operating Temperature |
85°C |
| Max Voltage Rating (DC) |
6V |
| Mechanical Life |
2kcycles |
| Min Operating Temperature |
-40°C |
| Mount |
Surface Mount |
| Number of Circuits |
2 |
| Number of Positions |
2 |
| Orientation |
Straight |
| Packaging |
Tape & Reel |
| Pitch |
2.54mm |
| Radiation Hardening |
No |
| REACH SVHC |
Yes |
| RoHS |
Compliant |
| Schedule B |
8536509065, 8536509065|8536509065|8536509065|8536509065|8536509065 |
| Sealable |
MOISTURE PROOF, TOP TAPE SEALED |
| Termination |
J-Bend |
| Throw Configuration |
SPST |
| Voltage Rating (DC) |
30V |
| Washable |
Yes |
