| Color | Beige, Black |
| Connector Type | Header |
| Contact Gender | Male |
| Contact Material | Brass |
| Contact Pitch | 2mm |
| Contact Plating | Gold |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 250V |
| Contact Voltage Rating (DC) | 250V |
| Current Rating | 2A |
| Depth | 6.2mm |
| Dielectric Material | Polyamide |
| Fastening Type | Detent |
| Gender | Male |
| Height | 7.2mm |
| Housing Color | Beige |
| Housing Material | Polyamide |
| Insulation Resistance | 1GΩ |
| Length | 9mm |
| Lifecycle Status | Production |
| Max Current Rating | 2A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 30V |
| Min Operating Temperature | -30°C |
| Mount | Surface Mount |
| Number of Contacts | 8 |
| Number of Pins | 8 |
| Number of Positions | 8 |
| Number of Rows | 2 |
| Operating Force | 4.3924N |
| Orientation | Straight |
| Pitch | 2mm |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 8.2804mm |
| Schedule B | 8536694040, 8536694040|8536694040|8536694040|8536694040|8536694040 |
| Terminal Pitch | 2mm |
| Termination | Solder |
| Voltage Rating | 250V |
| Width | 9.2mm |
