| Case/Package | 1209 |
| Case Code (Imperial) | 1209 |
| Case Code (Metric) | 3224 |
| China RoHS | Compliant |
| Color | Green |
| Contact Plating | Gold |
| Depth | 2.4mm |
| Dominant Wavelength | 569nm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Current | 30mA |
| Forward Voltage | 2.1V |
| Height | 2.4mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Green |
| Introduction Date | 2000-03-16 |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lens Color | Clear, Colorless |
| Lens Style | Clear |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 40mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Terminals | 2 |
| Peak Wavelength | 565nm |
| Power Dissipation | 100mW |
| Power Rating | 100mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000|8541402000|8541402000|8541402000 |
| Shape | Round |
| Terminal Pitch | 3.1mm |
| Test Current | 10mA |
| Viewing Angle | 25° |
| Wavelength | 565nm |
| Width | 2.4mm |
