| Case/Package | P |
| Clamping Voltage | 59.7V |
| Composition | Zener |
| Lead Free | Lead Free |
| Leakage Current | 2µA |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 44V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 8W |
| Max Reverse Leakage Current | 2µA |
| Max Surge Current | 251A |
| Min Breakdown Voltage | 40.2V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 36V |
| Packaging | Tape & Reel |
| Peak Pulse Current | 252.5A |
| Peak Pulse Power | 15kW |
| Polarity | Bidirectional |
| Power Line Protection | No |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 40.2V |
| Reverse Standoff Voltage | 36V |
| Reverse Voltage | 36V |
| RoHS | Compliant |
| Termination | Axial |
| Test Current | 5mA |
