| Breakdown Voltage |
11.7V |
| Case/Package |
P |
| China RoHS |
Non-Compliant |
| Clamping Voltage |
17V |
| Composition |
Zener |
| Diameter |
9.1mm |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Harmonized Tariff Schedule (HTS) Code |
8541.10.00.50 |
| Introduction Date |
1992-04-27 |
| Lead Free |
Lead Free |
| Leakage Current |
15µA |
| Length |
9.1mm |
| Lifecycle Status |
Production |
| Max Breakdown Voltage |
12.3V |
| Max Operating Temperature |
175°C |
| Max Power Dissipation |
8W |
| Max Reverse Leakage Current |
15µA |
| Max Surge Current |
295A |
| Min Breakdown Voltage |
11.1V |
| Min Operating Temperature |
-55°C |
| Mount |
Through Hole |
| Number of Channels |
1 |
| Number of Elements |
1 |
| Number of Pins |
2 |
| Number of Terminals |
2 |
| Number of Unidirectional Channels |
1 |
| Operating Supply Voltage |
10V |
| Packaging |
Cut Tape |
| Peak Pulse Current |
300A |
| Peak Pulse Power |
5kW |
| Polarity |
Unidirectional |
| Power Line Protection |
No |
| Power Rating |
5kW |
| REACH SVHC |
No |
| Reverse Breakdown Voltage |
11.1V |
| Reverse Standoff Voltage |
10V |
| Reverse Voltage |
10V |
| RoHS |
Compliant |
| Schedule B |
8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
| Termination |
Axial |
| Test Current |
5mA |
| Voltage Rating (DC) |
10V |
