| Breakdown Voltage | 120V |
| Clamping Voltage | 165V |
| Composition | Zener |
| Diameter | 2.7mm |
| Lead Free | Lead Free |
| Length | 5.2mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 126V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 1.5W |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 2.5A |
| Min Breakdown Voltage | 114V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 102V |
| Peak Pulse Current | 2.5A |
| Peak Pulse Power | 400W |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Power Rating | 400W |
| Reverse Standoff Voltage | 102V |
| Reverse Voltage | 102V |
| RoHS | Compliant |
| Termination | Axial |
| Test Current | 1mA |
| Voltage Rating (DC) | 120V |
Vishay
|
Production
|
Littelfuse
|
Production
|
Littelfuse
|
Obsolete
|
Taiwan Semiconductor
|
Unknown
|
Taiwan Semiconductor
|
Obsolete
|
