| Breakdown Voltage | 20V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 27.7V |
| Composition | Zener |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 2.29mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-10-16 |
| Lead Free | Lead Free |
| Length | 5.28mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 21V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 3.3W |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 14.8A |
| Min Breakdown Voltage | 19V |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 17.1V |
| Peak Pulse Current | 14.8A |
| Peak Pulse Power | 400W |
| Peak Reverse Current | 1µA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Power Rating | 400W |
| REACH SVHC | No |
| Reverse Standoff Voltage | 17.1V |
| Reverse Voltage | 17.1V |
| RoHS | Compliant |
| Schedule B | 8541100080 |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Voltage Rating (DC) | 20V |
| Width | 2.79mm |
