| Breakdown Voltage | 7.5V |
| Case/Package | SMA |
| China RoHS | Non-Compliant |
| Clamping Voltage | 11.3V |
| Composition | Zener |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 2.29mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-10-16 |
| Lead Free | Lead Free |
| Leakage Current | 1mA |
| Length | 5.28mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 7.88V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 3.3W |
| Max Reverse Leakage Current | 500µA |
| Max Surge Current | 4A |
| Min Breakdown Voltage | 7.13V |
| Min Operating Temperature | -65°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 64.1V |
| Peak Pulse Current | 36.3A |
| Peak Pulse Power | 400W |
| Peak Reverse Current | 1mA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Power Rating | 400W |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 7.13V |
| Reverse Standoff Voltage | 6.4V |
| Reverse Voltage | 6.4V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Test Current | 10mA |
| Voltage Rating (DC) | 7.5V |
| Width | 2.79mm |
