| Breakdown Voltage | 10V |
| Case/Package | DO-15 |
| China RoHS | Non-Compliant |
| Clamping Voltage | 14.5V |
| Composition | Zener |
| Diameter | 3.6mm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1996-01-01 |
| Lead Free | Lead Free |
| Leakage Current | 20µA |
| Length | 7.6mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 10.5V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Reverse Leakage Current | 10µA |
| Max Surge Current | 42.1A |
| Min Breakdown Voltage | 9.5V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 8.55V |
| Peak Pulse Current | 42.1A |
| Peak Pulse Power | 600W |
| Polarity | Bidirectional |
| Power Dissipation | 600W |
| Power Line Protection | No |
| Power Rating | 600W |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 9.5V |
| Reverse Standoff Voltage | 8.55V |
| Reverse Voltage | 8.55V |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
| Termination | Axial |
| Test Current | 1mA |
| Voltage Rating (DC) | 10V |
