| Projected EOL Date | 2034-09-22 |
| Access Time | 900ns |
| Contact Plating | Gold |
| Country of Assembly | Thailand |
| Country of Fabrication | N/A |
| Country of Origin | Thailand |
| Density | 2kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Height | 730µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | I2C, Serial |
| Introduction Date | 2008-09-22 |
| Length | 2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 400kHz |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 256B |
| Memory Type | EEPROM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 3mA |
| Number of Pins | 8 |
| Operating Supply Voltage | 5V |
| Packaging | Tape and Reel |
| RoHS | Compliant |
| Width | 3mm |
