| Projected EOL Date | 2034-09-08 |
| Case/Package | PDIP |
| Channel Type | Single |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 50ns |
| Height | 3.43mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Lead Free | Lead Free |
| Length | 9.65mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 85°C |
| Max Output Current | 12A |
| Max Power Dissipation | 960mW |
| Max Supply Voltage | 18V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Nominal Supply Current | 450µA |
| Number of Bits | 1 |
| Number of Channels | 1 |
| Number of Drivers | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 12A |
| Packaging | Bulk |
| Power Dissipation | 960mW |
| Propagation Delay | 60ns |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Turn-Off Delay Time | 80ns |
| Turn-On Delay Time | 80ns |
| Width | 6.48mm |
