| Projected EOL Date | 2034-12-06 |
| Case/Package | SOIC |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 33ns |
| Height | 1.4986mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.29.0095 |
| Input Bias Current | 10µA |
| Introduction Date | 2007-12-06 |
| Length | 4.8768mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 125°C |
| Max Output Current | 1.5A |
| Max Power Dissipation | 470mW |
| Max Supply Current | 4mA |
| Max Supply Voltage | 30V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 400µA |
| Number of Drivers | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 1.5A |
| Output Voltage | 29.2V |
| Power Dissipation | 470mW |
| Propagation Delay | 90ns |
| Radiation Hardening | No |
| REACH SVHC | No |
| Resistance | 12Ω |
| Rise Time | 25ns |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Turn-On Delay Time | 90ns |
| Width | 3.9116mm |
