| Case/Package | PLCC |
| Connector Type | Socket |
| Contact Material | Bronze |
| Contact Plating | Tin |
| Country of Origin | USA |
| Current Rating | 1A |
| Depth | 35.89mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gender | Female |
| Housing Material | Polyphenylene |
| Harmonized Tariff Schedule (HTS) Code | 8536.90.40.00 |
| Insulation Material | Polyphenylene |
| Insulation Resistance | 10GΩ |
| Introduction Date | 2005-12-14 |
| Lead Free | Lead Free |
| Lead Pitch | 1.27mm |
| Length | 35.89mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Contacts | 84 |
| Number of Pins | 84 |
| Number of Positions | 84 |
| Number of Rows | 4 |
| Orientation | Straight |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder |
| Width | 36.07mm |
