| China RoHS | Compliant |
| Clock Edge Trigger Type | Positive Edge |
| Country of Origin | Thailand |
| Direction | Unidirectional |
| Frequency | 90MHz |
| Height - Seated (Max) | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2012-07-12 |
| Length | 3.5mm |
| Lifecycle Status | Production |
| Load Capacitance | 50pF |
| Logic Function | Shift Register |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY |
| Max Operating Temperature | 125°C |
| Max Supply Current | 75mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Pins | 16 |
| Number of Terminals | 16 |
| Operating Supply Voltage | 5V |
| Packaging | Tape and Reel |
| Propagation Delay | 12ns |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Automotive |
| Terminal Pitch | 500µm |
| Width | 2.5mm |
