| Actuator Length | 5.5372mm |
| Actuator Material | Brass |
| China RoHS | Non-Compliant |
| Contact Current Rating | 3A |
| Contact Material | Silver |
| Contact Plating | Gold |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 125V |
| Current Rating | 3A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| Flammability Rating | UL94 V-0 |
| Height | 29.083mm |
| Housing Material | Nylon |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.70.00 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 1999-01-01 |
| Length | 15.7988mm |
| Life (Cycles) | 200kcycles |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 70°C |
| Mechanical Life | 200kcycles |
| Min Operating Temperature | -15°C |
| Mount | Panel |
| Power Rating | 400mW |
| REACH SVHC | No |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| Voltage Rating (DC) | 28V |
