| Actuator Length | 8.3058mm |
| Color | Black |
| Contact Current Rating | 3A |
| Contact Plating | Gold, Silver, Tin |
| Contact Resistance | 50mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 3A |
| Electrical Life | 100kcycles |
| Flammability Rating | UL94 V-0 |
| Height | 7.6mm |
| Housing Material | Polyamide |
| Illumination Color | Red |
| Illumination Type | LED |
| Insulation Resistance | 200MΩ |
| Lead Free | Contains Lead |
| Life (Cycles) | 1Mcycles |
| Lifecycle Status | Production |
| Max Current Rating | 3A |
| Max Operating Temperature | 50°C |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 1Mcycles |
| Min Operating Temperature | -25°C |
| Mount | Front, Panel |
| Operating Force | 1.67N |
| Orientation | Vertical |
| Packaging | Bulk |
| Ratings | Dust Tight, IP65, Water Resistant |
| REACH SVHC | No |
| RoHS | Compliant |
| Sealable | EPOXY TERMINAL SEALED, IP65 |
| Switch Function | On-Mom |
| Termination | Solder |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125V |
| Voltage Rating (DC) | 30V |
