| Breakdown Voltage | 180V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 246V |
| Contact Plating | Tin |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 3.5V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1994-05-01 |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 189V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Surge Current | 6.1A |
| Min Breakdown Voltage | 171V |
| Min Operating Temperature | -65°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 154V |
| Peak Pulse Power | 1.5kW |
| Peak Reverse Current | 5µA |
| Polarity | Unidirectional |
| REACH SVHC | No |
| Reverse Standoff Voltage | 154V |
| RoHS | Compliant |
| Termination | Axial |
