| China RoHS | Non-Compliant |
| Contact Plating | Tin |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| ESD Protection | No |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 10Ω |
| Introduction Date | 1994-01-01 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Material | Glass |
| Max Operating Temperature | 200°C |
| Max Power Dissipation | 1W |
| Max Reverse Leakage Current | 5µA |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Output Current | 1.3A |
| Peak Reverse Current | 5µA |
| Polarity | Unidirectional |
| Power Dissipation | 1W |
| Power Rating | 1W |
| REACH SVHC | Yes |
| Reference Voltage | 13V |
| Reverse Standoff Voltage | 9.9V |
| RoHS | Compliant |
| Test Current | 19mA |
| Tolerance | 5% |
| Voltage Rating (DC) | 13V |
| Voltage Tolerance | 5% |
| Weight | 245mg |
| Zener Current | 19mA |
| Zener Voltage | 13V |
