| Case/Package |
TO-126 |
| Collector Base Voltage (VCBO) |
80V |
| Collector Emitter Breakdown Voltage |
80V |
| Collector Emitter Saturation Voltage |
800mV |
| Collector Emitter Voltage (VCEO) |
80V |
| Current Rating |
4A |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Element Configuration |
Single |
| Emitter Base Voltage (VEBO) |
5V |
| Frequency |
3MHz |
| Gain Bandwidth Product |
3MHz |
| hFE Min |
15 |
| Harmonized Tariff Schedule (HTS) Code |
8541.29.00.95 |
| Introduction Date |
1999-01-01 |
| Lead Free |
Lead Free |
| Lifecycle Status |
Obsolete |
| Max Collector Current |
4A |
| Max Operating Temperature |
150°C |
| Max Power Dissipation |
36W |
| Min Operating Temperature |
-65°C |
| Mount |
Through Hole |
| Number of Elements |
1 |
| Number of Terminals |
3 |
| Polarity |
NPN |
| Power Dissipation |
36W |
| REACH SVHC |
Yes |
| RoHS |
Compliant |
| Transition Frequency |
3MHz |
| Voltage Rating (DC) |
80V |
| Weight |
761mg |
