| Collector Emitter Breakdown Voltage |
30V |
| Collector Emitter Voltage (VCEO) |
30V |
| Dark Current |
100nA |
| Forward Current |
60mA |
| Forward Voltage |
1.7V |
| Harmonized Tariff Schedule (HTS) Code |
8541.40.80.00 |
| Input Current |
1mA |
| Introduction Date |
1984-02-28 |
| Lead Free |
Lead Free |
| Lifecycle Status |
Obsolete |
| Max Collector Current |
3mA |
| Max Operating Temperature |
100°C |
| Min Operating Temperature |
-55°C |
| Mount |
Through Hole |
| Number of Channels |
1 |
| Number of Circuits |
1 |
| Number of Elements |
1 |
| Number of Pins |
4 |
| Operating Supply Voltage |
1.7V |
| Output Configuration |
Phototransistor |
| Output Voltage |
30V |
| Power Dissipation |
150mW |
| REACH SVHC |
Yes |
| Response Time |
50µs |
| Reverse Breakdown Voltage |
6V |
| Reverse Voltage (DC) |
6V |
| Rise Time |
8µs |
| RoHS |
Compliant |
| Sensing Distance |
2.9972mm |
| Voltage Rating (DC) |
30V |
