| Case/Package | TO-263-3 |
| China RoHS | Non-Compliant |
| Collector Base Voltage (VCBO) | 5V |
| Collector Emitter Saturation Voltage | 1V |
| Collector Emitter Voltage (VCEO) | 80V |
| Country of Origin | Malaysia |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | 5V |
| Gain Bandwidth Product | 50MHz |
| hFE Min | 40 |
| Introduction Date | 2001-04-01 |
| Lifecycle Status | Obsolete |
| Max Collector Current | 10A |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 50W |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 2 |
| Packaging | Tape and Reel |
| Polarity | NPN |
| REACH SVHC | No |
| RoHS | Non-Compliant |
| Transition Frequency | 50MHz |
| Voltage Rating (DC) | 80V |
