| Case/Package | TSSOP |
| China RoHS | Non-Compliant |
| Duty Cycle | 90% |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height - Seated (Max) | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2001-06-01 |
| Lead Free | Contains Lead |
| Length | 3mm |
| Lifecycle Status | Obsolete |
| Max Frequency | 216kHz |
| Max Operating Temperature | 85°C |
| Max Output Current | 150mA |
| Max Output Voltage | 1.948V |
| Max Supply Current | 90µA |
| Max Switching Frequency | 216kHz |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.853V |
| Nominal Input Voltage | 5V |
| Nominal Output Voltage | 1.9V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 5 |
| Output Voltage | 1.9V |
| REACH SVHC | No |
| RoHS | Non-Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 950µm |
| Topology | Boost |
| Width | 1.5mm |
