| Accuracy | 3% |
| Case/Package | TSSOP |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Country of Origin | Malaysia |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 990.6µm |
| Height - Seated (Max) | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2008-04-03 |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Input Voltage | 5.5V |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 85°C |
| Max Output Current | 150mA |
| Min Current Limit | 200mA |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.8V |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Regulators | 1 |
| Number of Terminals | 5 |
| Operating Supply Voltage | 5.5V |
| Output Current | 150mA |
| Output Type | Fixed |
| Output Voltage | 1.8V |
| Output Voltage Accuracy | 3% |
| Packaging | Tape & Reel (TR) |
| Polarity | Positive |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Pitch | 950µm |
| Voltage Tolerance | 3% |
| Width | 1.5mm |
