| Continuous Drain Current (ID) | 30A |
| Drain to Source Breakdown Voltage | -60V |
| Drain to Source Resistance | 65mΩ |
| Drain to Source Voltage (Vdss) | -60V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Fall Time | 18ns |
| Gate to Source Voltage (Vgs) | 20V |
| Height | 5.08mm |
| Introduction Date | 1998-09-01 |
| Lifecycle Status | Obsolete |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 135W |
| Min Breakdown Voltage | 60V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Power Dissipation | 135W |
| Rise Time | 23ns |
| RoHS | Non-Compliant |
| Turn-Off Delay Time | 28ns |
| Turn-On Delay Time | 15ns |
