| Breakdown Voltage | 176V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 243V |
| Composition | Zener |
| Contact Plating | Tin |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 3.5V |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-03-01 |
| Lead Free | Contains Lead |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 185V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 385mW |
| Min Breakdown Voltage | 167V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 700mA |
| Peak Pulse Power | 1kW |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 175W |
| REACH SVHC | No |
| Reverse Standoff Voltage | 150V |
| RoHS | Compliant |
| Voltage Rating (DC) | 150V |
| Width | 1.8mm |
Littelfuse
|
Obsolete
|
Diotec
|
Production
|
Central Semiconductor
|
Unknown
|
Littelfuse
|
Obsolete
|
Vishay
|
Obsolete
|
