| Breakdown Voltage |
6.6V |
| Capacitance |
400pF |
| Case/Package |
SC |
| China RoHS |
Non-Compliant |
| Clamping Voltage |
9.8V |
| Composition |
Zener |
| Depth |
1.5mm |
| Direction |
Unidirectional |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Harmonized Tariff Schedule (HTS) Code |
8541.10.00.50 |
| Introduction Date |
2001-03-01 |
| Lead Free |
Contains Lead |
| Leakage Current |
20µA |
| Length |
3mm |
| Lifecycle Status |
Obsolete |
| Max Breakdown Voltage |
7.2V |
| Max Operating Temperature |
150°C |
| Max Power Dissipation |
225mW |
| Max Surge Current |
23A |
| Min Breakdown Voltage |
6V |
| Min Operating Temperature |
-55°C |
| Number of Channels |
4 |
| Number of Elements |
4 |
| Number of Lines |
4 |
| Number of Pins |
6 |
| Number of Terminals |
6 |
| Number of Unidirectional Channels |
4 |
| Operating Supply Voltage |
5V |
| Packaging |
Tape and Reel |
| Peak Pulse Current |
23A |
| Peak Pulse Power |
350W |
| Peak Reverse Current |
20µA |
| Polarity |
Unidirectional |
| Power Line Protection |
No |
| Power Rating |
350W |
| Radiation Hardening |
No |
| REACH SVHC |
No |
| Reverse Standoff Voltage |
5V |
| RoHS |
Non-Compliant |
| Termination |
SMD/SMT |
| Voltage Rating (DC) |
5V |
| Width |
1.7mm |
| Working Voltage |
5V |
