| Breakdown Voltage | 18V |
| Capacitance | 95pF |
| Case/Package | SC |
| China RoHS | Non-Compliant |
| Clamping Voltage | 29V |
| Composition | Zener |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-07-01 |
| Lead Free | Contains Lead |
| Length | 3.1mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 19V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 150°C |
| Max Surge Current | 12A |
| Min Breakdown Voltage | 17V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 5 |
| Number of Elements | 5 |
| Number of Terminals | 6 |
| Number of Unidirectional Channels | 5 |
| Operating Supply Voltage | 15V |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 12A |
| Peak Pulse Power | 350W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 350W |
| REACH SVHC | No |
| Reverse Standoff Voltage | 15V |
| RoHS | Non-Compliant |
| Termination | SMD/SMT |
| Thickness | 1.1mm |
| Voltage Rating (DC) | 15V |
| Width | 1.7mm |
