| Case/Package |
TO-46 |
| Depth |
5.97mm |
| Fall Time |
250ns |
| Forward Current |
150mA |
| Forward Voltage |
2V |
| Height |
8.64mm |
| Housing Material |
Plastic |
| Lead Free |
Lead Free |
| Length |
5.97mm |
| Lens Style |
Circular, Dome |
| Lifecycle Status |
Production |
| Max Operating Temperature |
100°C |
| Max Power Dissipation |
1.11W |
| Min Operating Temperature |
-40°C |
| Mount |
Through Hole |
| Number of Circuits |
1 |
| Number of Elements |
1 |
| Number of LEDs |
1 |
| Number of Pins |
2 |
| Orientation |
Top View |
| Peak Wavelength |
890nm |
| Power Rating |
333mW |
| Radiation Hardening |
No |
| REACH SVHC |
Yes |
| Reverse Voltage |
2V |
| Rise Time |
500ns |
| RoHS |
Compliant |
| Shape |
Round |
| Test Current |
10mA |
| Viewing Angle |
50° |
| Wavelength |
890nm |
| Width |
5.97mm |
