| Case/Package | TO-18 |
| China RoHS | Compliant |
| Depth | 5.6mm |
| Fall Time | 500ns |
| Forward Current | 200mA |
| Forward Voltage | 1.5V |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 2001-02-23 |
| Lead Free | Lead Free |
| Length | 5.6mm |
| Lens Style | Circular, Dome, Round |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount, Through Hole |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Operating Supply Voltage | 1.5V |
| Orientation | Top View |
| Output Power | 12mW |
| Peak Wavelength | 880nm |
| Power Dissipation | 470mW |
| Power Rating | 470mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| Rise Time | 600ns |
| RoHS | Compliant |
| Shape | Round |
| Test Current | 100mA |
| Viewing Angle | 60° |
| Wavelength | 880nm |
