| Case/Package | SIP |
| Depth | 7.05mm |
| Efficiency | 60% |
| Features | SCP |
| Height | 10.2mm |
| Height - Seated (Max) | 10.45mm |
| Isolation | Isolated |
| Isolation Voltage | 1000Vrms |
| Lead Free | Lead Free |
| Length | 19.65mm |
| Lifecycle Status | Production |
| Max Input Voltage | 15.75V |
| Max Input Voltage (DC) | 15.75V |
| Max Operating Temperature | 70°C |
| Max Output Current | 200mA |
| Max Output Power | 1W |
| Max Output Voltage | 5V |
| Max Power Dissipation | 1W |
| Min Input Voltage | 14.25V |
| Min Input Voltage (DC) | 14.25V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Nominal Input Voltage | 15V |
| Nominal Output Voltage | 5V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Output Current | 200mA |
| Output Power | 1W |
| Output Voltage | 5V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Pitch | 2.54mm |
| Voltage - Output 1 | 5V |
| Weight | 2.8g |
| Width | 7.05mm |
