| Case/Package | MSOP |
| Data Rate | 20Mbps |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ESD Protection | Yes |
| Part Family | ISL3156E |
| Height | 850µm |
| Height - Seated (Max) | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8540000000 |
| Introduction Date | 2006-12-14 |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Logic Function | Receiver, Transceiver |
| Low Level Output Current | 8mA |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 85°C |
| Max Supply Current | 800µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| MSL | 1 |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Drivers | 1 |
| Number of Pins | 10 |
| Number of Receivers | 1 |
| Number of Terminals | 10 |
| Number of Transmitters | 1 |
| Operating Supply Voltage | 5V |
| Pitch | 500µm |
| Propagation Delay | 30ns |
| RAM Size | 48kB |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Simplex/Duplex | Full Duplex |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Width | 3mm |
Renesas
RS
RS
RS
DigiKey
Avnet Silica
Future Electronics
Avnet
Mouser
Renesas
|
Production
|
Renesas
|
Production
|
Sipex
|
Obsolete
|
Sipex
|
Obsolete
|
Renesas
|
Production
|
