| Case/Package | TSSOP |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height - Seated (Max) | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2004-04-23 |
| Length | 3mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 85°C |
| Max Reset Threshold Voltage | 4.75V |
| Max Supply Current | 3mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 4.5V |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Monitored Inputs | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 3mA |
| Operating Supply Voltage | 5V |
| Overvoltage Threshold | 4.75V |
| REACH SVHC | Yes |
| Reset | Active High |
| Reset Delay Time | 400ms |
| Reset Timeout | 100ms |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 650µm |
| Threshold Voltage | 4.62V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 4.5V |
| Watchdog Timer | Yes |
| Width | 3mm |
