| Case/Package | SOP |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.5mm |
| Height - Seated (Max) | 1.75mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2004-04-23 |
| Length | 4.9mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 85°C |
| Max Supply Current | 5mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 2.55V |
| Min Supply Voltage | 2.7V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Monitored Inputs | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 5mA |
| Operating Supply Voltage | 5V |
| Overvoltage Threshold | 2.7V |
| REACH SVHC | Yes |
| Reset | Active High |
| Reset Delay Time | 280ms |
| Reset Timeout | 100ms |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 1.27mm |
| Threshold Voltage | 2.63V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 2.55V |
| Watchdog Timer | No |
| Weight | 540.001716mg |
| Width | 3.9mm |
