| Approvals | CE, CSA, UL |
| Current Rating | 75A |
| Data Polarity | AC |
| Height | 20.32mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 20mA |
| Introduction Date | 2005-05-25 |
| Load Current | 75A |
| Max Length | 57.2mm |
| Max Operating Temperature | 80°C |
| Max Output Current | 75A |
| Max Output Voltage | 280V |
| Min Operating Temperature | -40°C |
| Mount | Panel, Screw |
| Number of Pins | 4 |
| RoHS | Compliant |
| Termination | Screw, Solder |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 280V |
