| Breakdown Voltage | 13.3V |
| Capacitance | 5pF |
| Case/Package | TO-253-4 |
| China RoHS | Compliant |
| Clamping Voltage | 31V |
| Country of Origin | Mainland China |
| Depth | 1.4mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-06-27 |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 3.04mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 13.3V |
| Max Operating Temperature | 125°C |
| Min Breakdown Voltage | 13.3V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 2 |
| Number of Channels | 2 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Number of Terminals | 4 |
| Packaging | Cut Tape |
| Peak Pulse Current | 16A |
| Peak Pulse Power | 500W |
| Polarity | Unidirectional |
| Power Line Protection | Yes |
| Power Rating | 500W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 12V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Voltage Rating (DC) | 12V |
| Width | 2.37mm |
| Working Voltage | 12V |
