| Case/Package | SOP |
| Channel Type | Unidirectional |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Data Rate | 1Mbps |
| Depth | 2.65mm |
| Height - Seated (Max) | 2.65mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.01 |
| Introduction Date | 2009-01-23 |
| Isolation Voltage | 2500Vrms |
| Length | 10.3mm |
| Lifecycle Status | NRND |
| Max Data Rate | 1 |
| Max Input Current | 6.8mA |
| Max Operating Temperature | 125°C |
| Max Propagation Delay | 35µs |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Outputs | 2 |
| Number of Pins | 16 |
| Number of Terminals | 16 |
| Operating Supply Current | 6mA |
| Polarity | Unidirectional |
| Propagation Delay | 35ns |
| REACH SVHC | Yes |
| Rise Time | 5ns |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Temperature Grade | Automotive |
| Terminal Pitch | 1.27mm |
| Turn-On Delay Time | 35ns |
| Type | General Purpose |
| Weight | 547.51434mg |
| Width | 7.5mm |
