| China RoHS |
Compliant |
| Collector Base Voltage (VCBO) |
230V |
| Collector Emitter Breakdown Voltage |
230V |
| Collector Emitter Saturation Voltage |
3V |
| Collector Emitter Voltage (VCEO) |
230V |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Element Configuration |
Single |
| Emitter Base Voltage (VEBO) |
5V |
| Frequency |
30MHz |
| Gain Bandwidth Product |
30MHz |
| Height |
18.7mm |
| hFE Min |
35 |
| Introduction Date |
2007-09-28 |
| Lead Free |
Lead Free |
| Length |
15.8mm |
| Lifecycle Status |
Obsolete |
| Max Breakdown Voltage |
230V |
| Max Collector Current |
15A |
| Max Frequency |
30MHz |
| Max Operating Temperature |
150°C |
| Max Power Dissipation |
130W |
| Min Operating Temperature |
-55°C |
| Mount |
Through Hole |
| Number of Elements |
1 |
| Number of Pins |
3 |
| Number of Terminals |
3 |
| Polarity |
PNP |
| Power Dissipation |
130W |
| Radiation Hardening |
No |
| REACH SVHC |
Yes |
| RoHS |
Compliant |
| Transition Frequency |
30MHz |
| Width |
5mm |
