| Case/Package |
SOT-32 |
| China RoHS |
Non-Compliant |
| Collector Base Voltage (VCBO) |
80V |
| Collector Emitter Breakdown Voltage |
80V |
| Collector Emitter Saturation Voltage |
800mV |
| Collector Emitter Voltage (VCEO) |
80V |
| Contact Plating |
Tin |
| Export Control Classification Number (ECCN) Code |
EAR99 |
| Element Configuration |
Single |
| Emitter Base Voltage (VEBO) |
5V |
| Frequency |
3MHz |
| Height |
10.8mm |
| hFE Min |
15 |
| Harmonized Tariff Schedule (HTS) Code |
8541.29.00.95 |
| Introduction Date |
1980-01-04 |
| Length |
7.8mm |
| Lifecycle Status |
Obsolete |
| Max Collector Current |
4A |
| Max Frequency |
3MHz |
| Max Operating Temperature |
150°C |
| Max Power Dissipation |
36W |
| Min Operating Temperature |
-65°C |
| Mount |
Through Hole |
| Number of Elements |
1 |
| Number of Pins |
3 |
| Number of Terminals |
3 |
| Packaging |
Bulk |
| Polarity |
PNP |
| Power Dissipation |
36W |
| Radiation Hardening |
No |
| REACH SVHC |
No |
| RoHS |
Compliant |
| Transition Frequency |
3MHz |
| Width |
2.7mm |
