| Breakdown Voltage | 28V |
| Capacitance | 60pF |
| Case/Package | SOT-23 |
| China RoHS | Compliant |
| Clamping Voltage | 45V |
| Composition | Zener |
| Country of Origin | Mainland China |
| Depth | 1.75mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Forward Voltage | 1.2V |
| Height | 1.3mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1980-01-04 |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 3.05mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 30V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 300W |
| Max Repetitive Reverse Voltage (Vrrm) | 24V |
| Max Reverse Leakage Current | 1µA |
| Min Breakdown Voltage | 25V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Number of Unidirectional Channels | 4 |
| Peak Pulse Power | 300W |
| Peak Reverse Current | 25µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 300W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 25V |
| Reverse Standoff Voltage | 24V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|8536300000|85 |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Voltage Rating (DC) | 25V |
| Width | 1.75mm |
| Working Voltage | 25V |
